Audio Technica Cardioid Condenser Microphone - AE5100

Audio Technica Cardioid Condenser Microphone - AE5100

Part Number: AE5100
Our Price: $299.00
This Item Is Discontinued
Free Shipping
This item qualifies for FREE GROUND SHIPPING! Contiguous U.S. only.

Description

Cardioid Condenser Instrument Microphone

The Artist Elite® AE5100 large diaphragm cardioid condenser instrument microphone provides uncompromising sound quality for overheads, percussion, acoustic guitar, strings and other acoustic instruments. With rich, warm, accurate sound, the AE5100 also incorporates the most essential ingredients for quality live sound in a choir microphone. Its large-diaphragm capsule delivers accurate, natural response, while its low-profile design permits innovative placement options. With a lower profile than the large studio microphones to which it compares sonically, the AE5100 offers an outstanding performance-to-size ratio. With its low noise and smooth response, the AE5100 is ideal for recording, too.

Key Features
  • Large-diaphragm capsule delivers accurate and natural response
  • Low-profile design permits innovative placement options previously unattainable with a large-diaphragm condenser
  • Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
  • Robust design for enduring dependability on the road
  • Includes isolation clamp for shock protection, secure mounting and easy positioning
  • Integral 80 Hz HPF switch and 10 dB pad

Specifications

ELEMENTFixed-charge back plate, permanently polarized condenser
POLAR PATTERNCardioid
FREQUENCY RESPONSE20-20,000 Hz
LOW FREQUENCY ROLL-OFF80 Hz, 12 dB/octave
OPEN CIRCUIT SENSITIVITY-36 dB (15.8 mV) re 1V at 1 Pa
IMPEDANCE150 ohms
MAXIMUM INPUT SOUND LEVEL148 dB SPL, 1 kHz at 1% T.H.D.;
158 dB SPL with 10 dB pad (nominal)
NOISE11 dB SPL
DYNAMIC RANGE (typical)137 dB, 1 kHz at Max SPL
SIGNAL-TO-NOISE RATIO83 dB, 1 kHz at 1 Pa
PHANTOM POWER REQUIREMENTS11-52V DC, 3.2 mA typical
SWITCHESHigh-pass filter;
10 dB pad (nominal)
WEIGHT5.0 oz (143 g)
DIMENSIONS5.85" (148.5 mm) long,
1.02" (26.0 mm) maximum diameter
OUTPUT CONNECTORIntegral 3-pin XLRM-type
ACCESSORIES FURNISHEDAT8471 isolation clamp for 5/8"-27 threaded stands; 5/8"-27 to 3/8"-16 threaded adapter; AT8136 windscreen; soft protective pouch
AUDIO-TECHNICA CASE STYLES4
