Description
Audio-Technica 3000 Series Body-Pack TX Bodypack Transmitter ATW-T3201EE1
The ATW-3212-C710EE1 includes an ATW-R3210 receiver and ATW-T3202 handheld transmitter with ATW-C710 cardioid dynamic microphone capsule. The Audio-Technica fourth-generation 3000 Series wireless systems give you the power and flexibility to operate within the congested UHF spectrum. 3000 Series systems have an operating range of 300′ (100 m) and are available in two frequency bands- DE2 (470-530 MHz) and EE1 (530-590 MHz) that provide a class-leading 60 MHz tuning range, which is more than twice that offered by the previous 3000 Series models. Frequencies can be easily scanned and selected on the receiver and then synced with the transmitter via IR sync functionality. The 3000 Series even lets you set a backup frequency that can be quickly swapped by pressing the transmitter’s multifunction button in the event of unexpected interference.
Key Features- Extremely wide 60 MHz UHF tuning bandwidth for maximum versatility in an increasingly congested RF environment; available in two frequency bands: DE2 (470-530 MHz) and EE1 (530-590 MHz)
- Unique multifunction button on the handheld and body-pack transmitters can be used to switch to a backup frequency (on both transmitter and receiver) should interference be encountered
- True Diversity operation reduces dropouts
- Auto Squelch feature automatically adjusts squelch setting to maximize range while minimizing potential interference
- Frequency scan and IR sync functionality for ease of setup
- Dual-mode receiver display can switch between standard view or a performance view that highlights key metering
- Transmitters and receivers include OLED screens for optimal readout of key settings and alerts
Specifications
Wireless Technology | Analog UHF |
RF Frequency Band | DE2: 470.125 to 529.975 MHz |
RF Bandwidth | 60 MHz |
Frequency Step Size | 25 kHz |
RF Channel Scanning | Auto-Scan |
Max Operating Range | 328.1' / 100 m |
Transmitter Type | Handheld |
RF Output Power | 10 / 30 mW (Switchable, at 50 Ohms) |
Modulation | FM |
Gain Range | -10 to +20 dB (2 dB Steps) |
