Aurora DVI w/Audio to HDMI Converter - ASP-DTH

Aurora DVI w/Audio to HDMI Converter - ASP-DTH

ASP-DTH DVI & Audio to HDMI Converter provides an easy and instant approach for converting digital video (DVI-D) and both digital audio (S/PDIF) and analog stereo audio to digital HDMI. With this module, DVI based devices such as PC with S/PDIF or analog stereo audio can readily connect to your HDMI TV at lowest cost.

Benefits:

• HDMI 1.2a compatible


• Fully HDCP compliant


• DVI video up to 165MHz


• Coaxial S/PDIF audio input


• Stereo analog audio input


• Front panel LED indicators


• Easy installation

Video Output
Bandwidth
165MHz [4.95Gbps]

Resolution
Up to single link: 1080p60, WUXGA [1920x1200@60Hz], UXGA [1600x1200@60Hz] Component video - 720p / 1080i

Connectors
Type A [19-pin female], DVI-I [29-pin female digital only], HD-15 [15-pin D-sub female], Coaxial S/PDIF digital audio [PCM 48kHz], Analog stereo audio

HDCP Compliant
Yes



Power
Power Supply
5V 2A DC

Power Consumption
4Watts



Physical
Dimensions
4.9" x 3.7" x 1" [125 x 95 x 25mm]

Weight
0.95lbs [430g]
