Aurora HDMI to DVI w/Audio Converter - ASP-HTD

Aurora HDMI to DVI w/Audio Converter - ASP-HTD

ASP-HTD HDMI to DVI & Audio Converter provides an easy and instant approach for converting digital HDMI to digital video (DVI-D) and both digital audio (S/PDIF) and analog stereo audio. With this module, HDMI based devices such as Blu-ray Disc players, PS3, DVD players, camcorders, or set-top boxes can readily connect to your PC LCD monitor and PC speakers at lowest cost. This device also enables users to connect full digital video and audio to DVI enabled monitor and S/PDIF equipped audio receiver and amplifier, and make the highest compatibility to your home theater devices.

Benefits:

• HDMI 1.2a compatible


• Fully HDCP compliant


• DVI video up to 165MHz


• Coaxial S/PDIF audio input


• Stereo analog audio input


• Front panel LED indicators


• Easy installation

Video Output
Bandwidth
165MHz [4.95Gbps]

Resolution
Up to 1080p60, WUXGA [1920x1200@60Hz], UXGA [1600x1200@60Hz]

Connectors
Type A [19-pin female], DVI-I [29-pin female digital only], Coaxial S/PDIF digital audio [PCM 48kHz], Analog stereo audio

HDCP Compliant
Yes



Power
Power Supply
5V 2A DC

Power Consumption
4Watts



Physical
Dimensions
3.5" x 6.2" x 1" [88 x 157 x 26mm]

Weight
0.78lbs [355g]
