Clear-Com Single-Channel Intercom Station with Loud Alert Buzzer - IKB-12P

Single-Channel Intercom Station with Loud Alert Buzzer

• Up to 64 intercom stations per system
• Configure up to 40 call buttons per station^*
• Plug-and-go installation with hardware discovery
• Audible and visual call signaling
• Web-browser configuration editor
• IP-65 rating^**

• Handset: 4-pin male XLR
• Ethernet/PoE: RJ-45

• Load Impedance: >32 Ohms
• Output Level: +1 dBu before clipping
• Sidetone: -6dB (selectable)
• Specified for a route from a 4-wire input @0dBu in:
• Max Gain: 12dB
• Noise: <-65dBu (@ max gain)
• Headphone Limiter: -0dBu, Selectable

• -14°F to +131°F (-10°C to +55°C)
• Humidity: 0 – 95%, relative

• 27.9 oz (0.79 kg)

• Handset Mic Impedance: 200 Ohms, Dynamic
• Mic Limiter Range: >35dB
• Mic Gain: 60dB, Dynamic
• Frequency Response: 400Hz – 8kHz, + 3dB (contoured for intelligibility)
• Distortion: < -55dBu, Dynamic

• Power Requirements: 5W DC
• Voltage Range: 30 – 60V

• Fast Ethernet Standard: 100 BaseT only, Auto MDIX

• 10 x 8 x 3.6 in (HxWxD)
• (254 x 203 x 93 mm)
