Covid Cables HDBaseT 1-Gang Tx, HDMI 4K, 18G, White THBW-210-WH

Covid THBW-210-WH HDBaseT 1-Gang Tx, HDMI 4K, 18G, White

The THBW-210 combines the high bandwidth of HDMI 2.0 with the far transmission distances of HDBaseT, in a customizable wall plate design. Utilizing a special HDMI-to-HDBaseT conversion processor, the THBW-210 can transmit up to 40 meters, 2160p@60Hz (4K – 18G) – far exceeding the 10.2Gbs limitation of standard HDBaseT hardware. In addition, the THBW-210 features RS232 pass-through and Power over Cable (PoC) to match performance with convenience.

• HDMI 2.0, HDCP 2.2 / HDCP 1.4
• Resolutions Up To 2160p@60Hz(4K - 18G)
• Audio up to 7.1 channels of High Definition audio pass through (LPCM, Dolby TrueHD, and DTS-HD Master Audio)
• HDBaseT over a single CAT 6/6a cable up to 230ft/70m distance 1080p or 131ft/40m at 4K60Hz
• PWR/LINK/HDCP indicators
• PoC (Power Over Cable) functionality is supported, either Tx or Rx is powered by a 24V@1A power supply. PoC Power consumption is less than 10W
• Bi-directional Infrared control signal together with the HDMI signal
• Bi-directional RS-232 control signal together with the HDMI signal
