Kramer 4x1 Computer Graphics Video & Stereo Audio Standby Switcher - VP-411DS

This item qualifies for FREE GROUND SHIPPING! Contiguous U.S. only.

Description

4x1 Computer Graphics Video & Stereo Audio Standby Switcher

The VP?411DS is a high?performance switcher for computer graphics video signals, with resolutions up to and exceeding UXGA, and unbalanced stereo audio signals. When configured as a standby switcher, the switching priority can be set for each of the four inputs.

Key Features

High Bandwidth - 300MHz (–3dB).
Looping Input - Input 1.
Automatic Standby Switching - Priority can be set for each of the 4 inputs via DIP–switches.
Kr–isp® Advanced Sync Processing - Ensures compatibility with a wide range of computers (even if the sync level is too low) by restoring the sync signal waveform. Kr–isp® advanced sync processing can be enabled or disabled.
Primary Input - Selectable.
Flexible Control Options - Front panel, RS–232 (K–Router™ Windows®–based Kramer software is included), contact closure, & IR remote (included).
Output Disconnect.
Front Panel Lockout.

Specifications

INPUTS	4 UXGA with loop on IN 1 on 15–pin HD connectors, 4 unbalanced stereo audio with loop on IN 1 on 3.5mm mini jacks
OUTPUTS	1 UXGA on a 15–pin HD connector, 1 unbalanced stereo audio on a 3.5mm mini jack
MAX. OUTPUT LEVEL	Video: 1.8Vpp Audio: 7.2Vpp
BANDWIDTH (-3DB)	Video: 300MHz Audio: >40kHz
DIFF. GAIN	0.03%
DIFF. PHASE	0.06Deg
K-FACTOR	<0.05%
S/N RATIO	Video: 73dB @5MHz Audio: 93dB
CROSSTALK (ALL HOSTILE)	Video: - 50dB @5MHz Audio: - 72dB @1kHz
CONTROLS	Input selector PANEL LOCK and OFF pushbuttons IR remote control reception window connector for extended IR reception RS–232 connector contact closure terminal block for external wire switching input priority selector DIP–switches normal/Kr–isp® and program/normal mode selectors via slide switches on the underside
COUPLING	Video: DC Audio: DC
AUDIO THD + NOISE	0.004% @1kHz
AUDIO 2ND HARMONIC	0.002% @1kHz
POWER CONSUMPTION	12V, 230mA
INCLUDED ACCESSORIES	Power supply, IR remote control
OPTIONS	RK–1 19" rack adapter, external remote IR receiver cable
PRODUCT DIMENSION	21.46cm x 16.30cm x 4.36cm (8.45" x 6.42" x 1.72" ) W, D, H
PRODUCT WEIGHT	0.7kg (1.5lbs) approx.
SHIPPING DIMENSION	35.10cm x 21.20cm x 7.20cm (13.82" x 8.35" x 2.83" ) W, D, H
SHIPPING WEIGHT	1.3kg (3.0lbs) approx.
