ZoomSHOT 20 SE QUSB System White - 999-69300-100W

ZoomSHOT 20 SE QUSB System White - 999-69300-100W

Part Number: 999-69300-100W
Our Price: $3,574.00
Availability: Usually ships the same business day
-
+

Description

A low-cost point-of-view camera with HD image quality.

    Key Features:
  • 20x powered zoom with 63° horizontal field of view
  • Up to 1080p/60 HD image quality
  • HDMI, YPbPr, and USB 2.0 or H.264 streaming outputs
  • Power/Video/Control on two Cat-5’s up to 150 ft (45.72 m)
  • Manual Pan/Tilt with EZ Set tensioning system

The ZoomSHOT 20 SE is a cost-effective, versatile, high-definition point-of-view camera well-suited for small, medium, and large rooms. It is designed to support a wide range of applications, including houses of worship, pro A/V system integration, live events, IMAG systems, UCC applications, videoconferencing, distance learning classrooms, and lecture capture. The camera captures with a full HD 1/2.8” Sony 1080p image sensor, 20x optical zoom, and 63° horizontal field of view. It also features a manual pan/tilt, an EZ Set tensioning system, and a presenter-friendly IR remote control. The ZoomSHOT 20 SE QUSB System is easy to install and use, and it offers a variety of outputs including simultaneous HDMI, component HD (YPbPr) and either USB 2.0 or IP Streaming. IP control of the ZoomSHOT camera is also available from the QUSB's web interface or telnet commands for a variety of control options. The ZoomSHOT 20 SE is a reliable and affordable solution for your video capture needs. Record a lecture, conduct a video conference, or capture live events with outstanding performance and quality. Versatile features, outputs, and ease of use, make this system an excellent choice. Additional ZoomSHOT 20 SE systems are available. For other outputs, see ZoomSHOT 20 SE QMini System or the ZoomSHOT 20 SE AVBMP for use with the AV Bridge MATRIX PRO (sold separately).

    This Package Includes:
  • ZoomSHOT 20 SE camera (black or white)
  • Thin Profile Wall Mount (black or white) with mounting hardware
  • Vaddio IR Shot Commander remote with 2x AAA batteries
  • Quick-Connect USB Interface
  • 24V power supply with AC cord set(s)

Specifications

Dimensions & Measurements DepthCamera: 5.8 in (14.73 cm) QUSB: 6 in (15.24 cm)
HeightCamera: 7 in (17.78 cm) QUSB: 1.72 in (4.37 cm)
Max Distance Support150 ft (45.7 m)
Product WeightCamera: 3.5 lbs (1.59 kg) QUSB: 1.4 lbs (0.64 kg)
Operating Temperature32° to 104°F (0° to 40°C)
WidthCamera: 5.5 in (14 cm) QUSB: 8.38 in (21.27 cm)
Characteristics & Features3rd Party ControlBuilt-in
Camera TypeFixed
ColorWhite
Compatible WithVaddio
Control Method
  • IR Remote
  • RS232
  • Estimated Room Size
  • Large Room
  • Medium Room
  • Field of View63 Degrees Wide End
    Field of View WideLess than 70
    Focus System
  • Auto
  • Manual
  • Gain
  • Auto
  • Manual
  • Image Sensor Type1/2.8 Exmor CMOS
    InvertibleYes
    ManufacturerVaddio
    Input PortsEZ Power Video
    Minimum Illumination0.3 Lux (F1.6)
    OneLINK CompatibilityNo
    Output Ports
  • HD YPbPr
  • HDMI
  • IP Streaming
  • USB 2.0
  • Pan and Tilt Range
  • Tilt: +30· to -30°
  • Unlimited Pan
  • Pan and Tilt SpeedManual
    Pixels2.14 Megapixel (2.38 Total MP)
    Power CordUS Cord
    Power Supply
  • 2.08A
  • 24VDC
  • Power TypeEZ Power
    Preset Positions16
    PTZ MotorsNo Motors Manual
    Quick-Connect CompatibilityQUSB
    Signal Type
  • HD YPbPr
  • HDMI
  • IP Streaming
  • RS 232
  • USB 2.0
  • Solution TypeCamera with Extension
    Top Resolution1080p 60
    Tri-Sync MotionNo
    White Balance
  • Auto
  • Manual
  • Zoom20x
    Zoom RangeGreater than 19X
    Certifications & WarrantiesCertifications
  • CE
  • FCC
  • TAA
  • Warranty3 years
