Yamaha VXC8SW 8" Band-Pass In-Ceiling 200W Subwoofer WITH AB-C8S

This item qualifies for FREE GROUND SHIPPING! Contiguous U.S. only.

Description

Yamaha VXC8SW 8" Band-Pass In-Ceiling 200W Subwoofer WITH AB-C8S, White

VXC series “S model" ceiling subwoofers are ideal matches for VXS and VXC series speakers, smoothly extending the low frequency range with superb sonic quality for bigger, more true-to-life musical reproduction without spoiling interior design of architectures.

Key Features

Sound and size ideally matched to the VXS and VXC series
Band-pass design ensures smooth, distortion-free low-frequency extension
Direct support for low-impedance or high-impedance connections
Built-in carrying band increases safety during installation
Anti-drop tab mechanism provide secure temporary positioning during installation
Double-threaded speaker clamp screws for speedy tightening

Specifications

Speaker type	Band-pass type Subwoofer
LF Component	8" Cone
Frequency Range (-10 dB)	44 Hz - 200 Hz (Half-space 2?)
Nominal impedance	8 ?
SPL Sensitivity (1W; 1m on axis)	88 dB SPL (Half-space 2?)
I/O connectors	Euroblock (4 pin) × 1 (input: +/-, loop-thru: +/-)
Cutout size	Ø285 mm (Ø11-7/32")
Power rating	NOISE 100 W, PGM 200 W
